Blue/Green Deployments

This page is a work in progress – Beau

Blue/Green deployment runs two stacks side-by-side: one live, one idle. You deploy to the idle stack, test it, and when ready, swap roles. It gives near-zero downtime and easy rollback.

Blue/Green adds some complexity because where before there was just "the stack", now there is:

1. A blue stack
2. A green stack
3. A proxy to direct traffic
4. An external Postgres container.

1. Caddy Adjustments

Name the Caddy containers

Naming the Caddy containers blue_caddy and green_caddy allows the proxy to direct traffic to the correct stacks:

compose.yaml

caddy:
  container_name: ${STACK_NAME}_caddy

Remove exposed ports

We'll no longer expose ports in our stacks. Instead a proxy will sit in front of the two stacks, proxying to them.

Remove the Caddy service's ports: section in compose.yaml.

Serve HTTP-only in the stacks

Set CADDY_SITE_ADDRESS to only :80, removing :443, leaving TLS termination to the proxy:

compose.yaml

caddy:
  environment:
    CADDY_SITE_ADDRESS: :80

2. Postgres

In regular SuperStack, Postgres comes up with the stack. But now we're bringing up two stacks, we can't have two Postgres containers both simultaneously accessing the same shared volume. We need a single Postgres container, separate from the stacks.

Add a profile to the Postgres service:

compose.yaml

postgres:
  profiles: ["db"]

Add it to the Compose file:

compose.yaml

networks:
  postgres:
    name: postgres
    external: true

Then in services that need database access (such as PostgREST):

compose.yaml

networks:
  - postgres

Move Postgres out of compose.yaml into a shared-compose.yaml, adding the shared network:

3. Volumes

To share data between the two stacks (uploads, etc.), give volumes explicit names:

compose.yaml

volumes:
  user_data:
    name: user-data

4. Bring up two Stacks

Deploying is the same as before, but now we're deploying the idle stack. For this example, green is idle so that's the one we're deploying.

Create blue and green directories on the server and copy compose.yaml into the idle stack's directory:

scp compose.yaml youruser@yourserver:green/compose.yaml

Shell into the server and bring up the idle stack:

cd green
docker compose pull
STACK_NAME=green docker compose up -d

Docker will use the directory name green as the project name, creating different containers, volumes and networks than the blue stack.

5. Add a Proxy

The proxy is a single container that binds ports 80 and 443 on the server and routes requests into either the Blue or Green stack.

On the server, create a simple Caddyfile:

caddy/Caddyfile

api.myapp.com {
  reverse_proxy blue_caddy:80
}

Optionally, point a second hostname to the idle stack for testing.

The front proxy manages TLS, so give it a persistent volume for certificates:

docker volume create caddy_data

Start the proxy, attaching it to both networks – this requires both stacks to be up first, so the networks exist:

docker run -d \
  --name front-proxy \
  -p 80:80 -p 443:443 \
  -v ./caddy:/etc/caddy \
  -v caddy_data:/data \
  --network blue_default \
  --network green_default \
  caddy:2

6. Upgrading

Flip traffic

Point traffic to the green stack:

Caddyfile

api.myapp.com {
  reverse_proxy green_caddy:80
}

Reload the proxy's config:

docker exec front-proxy caddy reload

Cutover is instant. Green is now live, and Blue is the idle stack.

And rollback is simple: flip the Caddyfile back and caddy reload again.

Github Actions

Here's a workflow for B/G deploys:

Click to expand

.github/workflows/ci.yaml

name: Deploy

on:
  push:
    branches:
      - main

jobs:
  deploy:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout code
        uses: actions/checkout@v4

      - name: Start SSH agent
        uses: webfactory/ssh-agent@v0.9.0
        with:
          ssh-private-key: ${{ secrets.VPS_SSH_KEY }}

      - name: Get the idle stack
        id: idle
        run: |
          ACTIVE=$(ssh -i ~/.ssh/id_rsa -o StrictHostKeyChecking=no \
            ${{ secrets.VPS_USER }}@${{ secrets.VPS_HOST }} \
            'cat active_stack 2>/dev/null || echo blue')

          if [ "$ACTIVE" = "blue" ]; then
            echo "IDLE=green" >> $GITHUB_OUTPUT
          else
            echo "IDLE=blue" >> $GITHUB_OUTPUT
          fi
          echo "ACTIVE=$ACTIVE" >> $GITHUB_OUTPUT

      - name: Copy compose.yaml to idle stack
        uses: appleboy/scp-action@master
        with:
          host: ${{ secrets.VPS_HOST }}
          username: ${{ secrets.VPS_USER }}
          port: 22
          key: ${{ secrets.VPS_SSH_KEY }}
          source: "compose.yaml"
          target: "${{ steps.idle.outputs.IDLE }}/"

      - name: Deploy idle stack
        uses: appleboy/ssh-action@v1.0.3
        with:
          host: ${{ secrets.VPS_HOST }}
          username: ${{ secrets.VPS_USER }}
          key: ${{ secrets.VPS_SSH_KEY }}
          envs: GHCR_PAT
          script: |
            set -euo pipefail
            echo "${{ steps.idle.outputs.ACTIVE }}" > active_stack
            cd ${{ steps.idle.outputs.IDLE }}
            echo "$GHCR_PAT" | docker login ghcr.io -u "${{ github.actor }}" --password-stdin
            DOCKER_CLIENT_TIMEOUT=300 COMPOSE_HTTP_TIMEOUT=300 docker compose pull -q
            STACK_NAME=${{ steps.idle.outputs.IDLE }} docker compose up -d
        env:
          GHCR_PAT: ${{ secrets.GHCR_PAT }}

If you want to auto-flip between blue and green, add this extra task:

- name: Flip traffic
  uses: appleboy/ssh-action@v1.0.3
  with:
    host: ${{ secrets.VPS_HOST }}
    username: ${{ secrets.VPS_USER }}
    key: ${{ secrets.VPS_SSH_KEY }}
    script: |
      if [ "${{ steps.idle.outputs.IDLE }}" = "blue" ]; then
        sed -i 's/green_caddy/blue_caddy/g' caddy/Caddyfile
      else
        sed -i 's/blue_caddy/green_caddy/g' caddy/Caddyfile
      fi
      docker exec front-proxy caddy reload --config /etc/caddy/Caddyfile
      echo "${{ steps.idle.outputs.IDLE }}" > active_stack
